Features
Bluetooth® audio streaming and telephony support
The two full-range, multi-channel GTR amplifiers (104 and 7535 models) feature Bluetooth® connectivity for wireless audio streaming from phones and other devices. You can receive phone calls through your car audio system, just by touching a button on an included control panel.
Clari-Fi™ audio restoration technology
Clari-Fi™, a proprietary DSP technology, is incorporated in the GTR-104 and GTR-7535 amplifiers, analyzes music files and improves highly compressed digital music files in real time. A predictive algorithm restores audio content that is discarded in the compression process. Clari-Fi™ works with all playback devices and audio sources. It extends high-frequency bandwidth, restores the natural warmth of vocals and widens the sound stage. In short, Clari-Fi™ gives your digital music back its soul.
Party Mode wireless pairing
The GTR-104 and GTR-7535 amplifiers offer Party Mode, a multi-pairing capability that enables Bluetooth® devices to stream audio individually. When Party Mode is selected from the cabin-mounted control panel, anyone in the car can drive the music.
Cabin-mounted control panel
The GTR-104 and GTR-7535 multi-channel amps come with a wired control panel that incorporates an omni-directional microphone and puts a range of functions at your fingertips. You can activate Bluetooth® pairings, accept and end phone calls, select Party Mode and cancel Clari-Fi™.
Class D amplification
Every GTR amplifier, including the full-range models, is a Class D. These high-efficiency, low-heat amps generate a lot of power without drawing much current, and feature small footprints.
Full-range line outputs
The GTR-104 includes full-range line outputs. This enables them to pass the audio signal to additional amps that power subwoofers, increasing your system configuration options.
High-Level Low Level Inputs
The GTR-104 will accept both high level and low level inputs which allows for interface to both factory head units and aftermarket head units. A simple switch is provided to properly set the input level correctly. To ease installation from high-level inputs, proprietary bare wire to RCA connector adapters are included.
Variable Electronic Crossover
The GTR-104 has a built-in variable electronic crossover which allows for precision tuning of your speakers. You are able to select full-range, high-pass or low-pass with tuning available from 32Hz- 320Hz. On the GTR-104 you can also set the fron ttwo channels and rear two channels independantly which can com ein handy if you are running different sized speakers or running full range speakers and a pair of subwoofers. Our crossovers are low-noise and easily adjustable using a small slotted screwdriver versus finger controlled crossovers to ensure the setting stays put.
Specs & Downloads
Item#: GTR-104-Z
Product Description
GTR Stadium Amplifiers
General Specifications
Audio Specifications
What's in the box?
- 1 amplifier
- 1 cabin-mounted control panel
- 2 spare fuses
- Owner’s manual
Documents & Downloads
The latest owner's manuals, quick start guides, and documents.
