JBL GTR-104-Z

GRAND TOURING GTR 104 Refurbished

100W RMS 4-Channel Stadium Series Bluetooth Car Amplifier with Clari-Fi Technology and Party Mode

Variations
For Bulk Enquiry: Click Here

Features

Bluetooth® audio streaming and telephony support

Bluetooth® audio streaming and telephony support

The two full-range, multi-channel GTR amplifiers (104 and 7535 models) feature Bluetooth® connectivity for wireless audio streaming from phones and other devices. You can receive phone calls through your car audio system, just by touching a button on an included control panel.

Clari-Fi™ audio restoration technology

Clari-Fi™ audio restoration technology

Clari-Fi™, a proprietary DSP technology, is incorporated in the GTR-104 and GTR-7535 amplifiers, analyzes music files and improves highly compressed digital music files in real time. A predictive algorithm restores audio content that is discarded in the compression process. Clari-Fi™ works with all playback devices and audio sources. It extends high-frequency bandwidth, restores the natural warmth of vocals and widens the sound stage. In short, Clari-Fi™ gives your digital music back its soul.

Party Mode wireless pairing

Party Mode wireless pairing

The GTR-104 and GTR-7535 amplifiers offer Party Mode, a multi-pairing capability that enables Bluetooth® devices to stream audio individually. When Party Mode is selected from the cabin-mounted control panel, anyone in the car can drive the music.

Cabin-mounted control panel

Cabin-mounted control panel

The GTR-104 and GTR-7535 multi-channel amps come with a wired control panel that incorporates an omni-directional microphone and puts a range of functions at your fingertips. You can activate Bluetooth® pairings, accept and end phone calls, select Party Mode and cancel Clari-Fi™.

Class D amplification

Class D amplification

Every GTR amplifier, including the full-range models, is a Class D. These high-efficiency, low-heat amps generate a lot of power without drawing much current, and feature small footprints.

Full-range line outputs

Full-range line outputs

The GTR-104 includes full-range line outputs. This enables them to pass the audio signal to additional amps that power subwoofers, increasing your system configuration options.

High-Level Low Level Inputs

High-Level Low Level Inputs

The GTR-104 will accept both high level and low level inputs which allows for interface to both factory head units and aftermarket head units. A simple switch is provided to properly set the input level correctly. To ease installation from high-level inputs, proprietary bare wire to RCA connector adapters are included.

Variable Electronic Crossover

Variable Electronic Crossover

The GTR-104 has a built-in variable electronic crossover which allows for precision tuning of your speakers. You are able to select full-range, high-pass or low-pass with tuning available from 32Hz- 320Hz. On the GTR-104 you can also set the fron ttwo channels and rear two channels independantly which can com ein handy if you are running different sized speakers or running full range speakers and a pair of subwoofers. Our crossovers are low-noise and easily adjustable using a small slotted screwdriver versus finger controlled crossovers to ensure the setting stays put.

Specs & Downloads

Item# GTR-104-Z

Product Description

GTR Stadium Amplifiers

Max Power: 1500W Peak Power Output, 4Ω: 100Wrms x 4, <0.1% THD+N Power Output, 2Ω: 120Wrms x 4, <0.1% THD+N Power Output, 4Ω Bridged: 240Wrms x 2, <0.3% THD+N Signal-to-Noise Ratio: >75dB (ref 1 W output @ 4Ω) Bluetooth® Audio Streaming Clari-fi™ Music Restoration Technology Party Mode allows sharing of streaming content Cabin Controls and Telephone Integration High Efficiency, Low Distortion Class D Design

General Specifications

Peak Power 1500W

Audio Specifications

2-Ohm Power Output 120Wrms x 4, <0.1% THD+N
Signal-to-Noise Ratio >75dB (ref 1 W output @ 4 )
4-Ohm Power Output 100Wrms x 4, <0.1% THD+N

What's in the box?

  • 1 amplifier
  • 1 cabin-mounted control panel
  • 2 spare fuses
  • Owner’s manual
