Features
110W power output
Incredible, powerful sound for an immersive cinematic experience.
Wired subwoofer for extra deep bass
Enjoy deep and thrilling bass.
Dolby Digital embedded
Dolby Digital embedded for the ultimate movie experience.
Wireless music streaming via Bluetooth
Stream and enjoy all your music wirelessly from any mobile device.
One cable connection with HDMI ARC
The one cable HDMI ARC connection allows for the simplest set-up and a hassle-free user experience.
Specs & Downloads
Item# JBLSB130BLKAS
Product Description
Extra Bass. Powerful sound.
The JBL Cinema SB130 features 110W system power, Dolby Digital, two full range drivers and comes with a wired subwoofer. Enjoy powerful sound with extra deep bass for movies and music entertainment. It’s Bluetooth-enabled so you can play your favorite music wirelessly from any smartphone, tablet or laptop and features a one cable connection with HDMI ARC that ensures a hassle-free user experience.
General Specifications
Power supply
100 - 240VAC, ~ 50/60Hz
Total speaker power output (Max. @THD 1%)
110W
Soundbar power output (Max. @THD 1%)
2 x 27W
Subwoofer power output (Max. @THD 1%)
56W
Soundbar transducer
2 x 2" full range driver
Subwoofer transducer
4", wired sub
Operating temperature
0°C - 45°C
Audio Specifications
Max SPL
82dB
Frequency response
40Hz - 20kHz
Audio inputs
1 Optical, Bluetooth
(USB is for Service only.)
Dimensions
Soundbar dimensions (W x H x D)
900 x 67 x 63(mm) / 35.4" x 2.6" x 2.5"
Subwoofer dimensions (W x H x D)
150 x 320 x 220(mm) / 6" x 12.6" x 8.7"
Soundbar weight
1.5kg
Subwoofer weight
2.8kg
Packaging dimensions (W x H x D)
975 x 170 x 355mm / 38.4" x 6.7" x 14"
Packaging weight (Gross weight)
5.8kg
Control and Connection Specifications
Bluetooth version
4.2
Bluetooth profile
A2DP V1.3/AVRCP V1.5
Bluetooth frequency range
2402MHz-2480MHz
Modulation type
GFSK, π/4 DQPSK
USB port
Type A
USB rating
5VDC/0.5A
Supporting file format
mp3, wav
MP3 Codec
MPEG 1 Layer 2/3
MPEG 2 Layer 3
Yes
MPEG 2.5 Layer 3
Yes
MP3 sampling rate
16kHz - 48kHz
MP3 bitrate
80kbps - 320kbps
80kbps - 160kbps (MPEG 2.5 Layer 3)
Yes
WAV sample rate
16kHz - 48kHz
WAV bitrate
Up to 3000kbps
What's in the box?
- Soundbar
- Wired subwoofer
- Remote control with batteries
- Power cords (up to 4pcs depending on region SKUs)
- HDMI cable
- Wall-mount bracket kit with screws
- Quick start guide
- Warranty card
- Safety sheet
Documents & Downloads
The latest owner's manuals, quick start guides, and documents.
